Can Beverage Filling Machine
Can Beverage Filling Machine
This machine can precisely fill all kind of beverage and beer for aluminum cans, All parts of this machine is made of stainless steel materials, it cannot cause rust to influence the filling beverage, it not only reach the standard of sanitation, but also prolong its using life.
Automatic Aluminum Can Filling Machine for Sale
KING MACHINE can filler The method of operation of the new filling valve The can is fed into the filler and positioned underneath the filling valve. The valve is pneumatically lowered onto the can for pressing-on. Thanks to a differential pressure chamber, the cans are also centred and pressed onto the valve with extreme care. The filling process begins immediately after flushing. An inductive flow meter checks the quality of inflowing liquid. The valve closes once the specified filling volume has been reached. Optional − Cleaning in a closed system using automatically
| Technical parameter :Fully Automatic Flowmeter type Can Filler/Seamer for CSD | |||||
| Model | GDF12-1 | GDF18-4 | GDF32-6 | GDF40-6 | GDF54-6 |
| Capacity(cans/hour) | 2000 | 8000 | 15000 | 20000 | 30000 |
| Suitable container | Aluminum Can / Tin Can / Plastic Can | ||||
| Can diameter | Dia50 ~ dia99mm | ||||
| Can height (mm) | 70-175mm | ||||
| Compressor air | Isobaric filling / normal pressure filling | ||||
| Application | Beverage Can Filling Machine | ||||
| Total power (kw) | 2.4kw | 4.4kw | 6.2kw | 7.2kw | 16kw |
| Overall dimensions | 2.5*1.9m | 2.8*1.9m | 3.2*2.5m | 3.8*2.8m | 3.8*2.8m |
| Height | 2.3m | 2.5m | 2.5m | 2.5m | 2.5m |
| Weight(kg) | 2500kg | 3200kg | 4500kg | 6500kg | 10000kg |
We also make our innovative, state-of-the art technology available to small and medium-sized breweries. This is demonstrated by our King Machine CAN Compact can filler which gives operators established high-tech in a particularly compact space. The filler, valve manifold, seamer, control cabinet and paneling form a closed unit. The King Machine CAN Compact fills between 5,000 and 28,000 cans per hour and is thus especially suitable for craft brewers.
Benefits of Automatic Liquid Filling Machinery for Water Bottles
King Machine offers a wide range of machinery solutions capable of filling for low-viscosity liquids such as water with the bottle shape like PET circular or square. The following are the benefits of installation of a liquid filling machine in your assembly line.
Higher Productivity
Higher Productivity is an important goall of beverage companies. The machine has adjustable speed limits to increase and decrease the speed as and when required. The production can be regulated as per demand forces in the market, leading to higher productivity.
Cost-effective and time-saving
Purchasing water filling machines is a high investment, but it is the best strategy to reduce labor and time costs. The companies can focus on more fruitful sources of the business without time waste.
Looking for water bottling machine products for your project? Contact us today for a quick quote.
